Circuit Board Apparatus STEM Lab

Circuit Board Apparatus STEM Lab

Product Code : SCL-EI-12553

Quick Answer: The Circuit Board Apparatus STEM Lab is an FR4 fibreglass circuit board with printed circuit symbols, 24 colour-coded 4mm sockets, lamps, LEDs, switches, passive components and a 0.5A fuse, for building series, parallel and mixed circuits without soldering. It runs on 4 AA cells or a 0–12V DC lab supply.

Last updated: October 2026

Key Features

  • FR4 fibreglass board with screen-printed circuit symbols and trace paths
  • 24 red and black 4mm shrouded banana sockets and nickel-plated spring posts
  • 3 miniature incandescent lamps (3.8V) and 2 LEDs with current-limiting resistors
  • Fixed resistors, a potentiometer, an electrolytic capacitor and a silicon diode
  • 1 SPST knife switch and 1 SPDT selector switch
  • Panel-mounted 0.5A fast-blow glass fuse holder

Technical Specifications

SpecificationValue
BoardFR4 fibreglass with insulated backing
Terminals24 colour-coded 4mm shrouded banana sockets, spring posts
Lamps3 miniature incandescent (3.8V), 2 LEDs
Switches1 SPST knife switch, 1 SPDT selector switch
Fuse0.5A fast-blow glass fuse
Battery input4 x 1.5V AA
External supply0–12V regulated DC
WeightApprox. 680 grams

About This Product

Students plug components into the printed layout and follow the current path by eye as they build series, parallel and series-parallel networks, measuring voltages and currents to check Ohm’s law and Kirchhoff’s laws. The capacitor and diode extend the work to RC charging and rectification, and the fuse shows how an overload breaks a circuit. The board is for low-voltage DC only, up to 12V, and must never be connected to mains.

Frequently Asked Questions

What can power the Circuit Board Apparatus STEM Lab?

Four 1.5V AA cells in the rear battery bay, or an external regulated DC supply of 0–12V. It must not be connected to AC mains.

Related: Electronic Instruments and Hand Battery Apparatus STEM Lab.

For a quotation on the Circuit Board Apparatus STEM Lab, contact Educational Instrument.
