Pin-Jointed Frameworks

Pin-Jointed Frameworks

Product Code : EL-NGSP-11395

Quick Answer: The Pin-Jointed Frameworks experiment uses strain gauges, read through a strain gauge amplifier, to find the member forces in a roof truss under load. Load cells can apply angled loads, and an optional load cell adds a secondary load to the side of the truss.

Last updated: October 2026

Key Features

  • Strain gauges connect to a strain gauge amplifier and on to the USB interface hub of the Structures platform
  • Load cells can apply angled loads, including a simulated swaying load
  • Optional load cell for a secondary load on the side of the roof truss

About This Product

Students predict the member forces and deflections of the framework for a given load with textbook equations, then compare the predictions with the measured results. Educational Instrument can dispatch the Pin-Jointed Frameworks to laboratories in Italy, Afghanistan, Burkina Faso, Australia, Cyprus and Ecuador.

Related: Next Generation Structures Products, Redundant Truss, Frame Deflections and Reactions and Structures Platform Next Generation Structures.

For a quotation on the Pin-Jointed Frameworks, contact Educational Instrument.
